Model

MR-300S

MR-450

MR-400

MR-400TO

MR-400DS

MR-400DD

Flux System

Flux Storage Tank

1L

1L

1L

1L

1L

1L

Flux Support

Flux Alarm, Automatic

Spray Nozzle

Jet Valve (Spot and line spraying) 1set

Spray Nozzle Size

130um (180, 210um Option)

Spray Range

3~8mm

Spray speed

0~20mm/s

Spray Nozzle move speed

0~400mm/s

Spray Precision

0.1mm

Spray Pressure

0.05~0.1MPa

Spray Height Adjustment

Auto

Spray nozzle jam detection

Option

Flux Tank

Pressure tank

Alcohol Tank

Pressure tank

Preheating System

Preheating Mode

N/A

Hot air

Hot air

Hot air and IR

Hot air and IR

Hot air and IR

Preheating Zone

N/A

Top hot air

Top hot air

Top hot air: 1

Bottom IR: 1

Top hot air: 1

Bottom IR: 1

Top hot air: 1

Bottom IR: 1

Bottom Preheating power

Max.12kw

Top Preheating power

Max.6kw

Preheating Temp

(Room Temperature) -250℃

Warm-up Time

Approx.15min (setting 150℃)

Control Mode

PC+PLC

Soldering System

Nozzle Inner Diameter

Φ 2.5-30mm(standard 5 nozzle :3/4/6/8/10;Customization Special dimensions)

Wave Height

3~8mm

Solder Pot Z axis Area

50 mm

Soldering Precision

±0.15 mm

Solder Pot Drive

Single Pot: XYZ independent drive

Dual Pot: Dual Y axis, dual Z axis independent drive, synchronous or asynchronous action (option)

Dual Pot Clearance

Min: 100mm~300mm (Only for dual soldering pot)

Auto feeding solder wire

Optional, Tin wire Φ2mm, Max. 4kg

Solder liquid level detection

High precision sensor

Soldering height detection

Optional Laser sensor

Solder Pot move speed

0~400mm/s

Solder Pot Z axis speed

0~100mm/S

Soldering monitoring

CCD

Wave Control

Mechanical pump，Electromagnetic pump is option

Solder Pot Quantity

1 set

1 set

1 set

1 set

2 set

4 set

Solder Pot power

1.35kw

1.35kw

1.35kw

1.35kw

1.35kw*2

1.35kw*4

Solder Pot

Titanium alloy

Solder Capacity

15Kg

Max. Temperature

350℃

Heating Control

PID + SSR

Temperature Accuracy

±1℃

Warm-up Time

<60min (setting 300℃)

Transport System

Max Fixture Size

300*300

450*400

500*450

500*500

500*500

500*500

Max PCB Size

300*300

450*400

500*450

500*500

500*500

500*500

Components lead pin pitch

≥0.5mm

Components and Pad Clearance

≥1.5mm

PCB Top Clearance

120mm

PCB Bottom Clearance

30mm

PCB Weight

<20Kg

PCB Thickness

0.5-6.0mm

Clearance from PCB edge

4mm

Transport Height

900±20mm

Transport Direction

L~ R (R~L)

Width Adjustment

Auto

Transport Mode

Roller, Segmented transportation

Software System

Operating System

Windows10

Language

Chinese, English, languages can be switched.

Program Import

CCD shooting, Picture import

Option

Nozzle Type Auto Identify, Soldering Nozzle Jet-flow Status Real Time Monitoring, Barcode Scanner

Facility

N2 Purity

Purity of N2: 99.999%, 25 L/min, Outer diameter Φ6mm

N2 Pressure

0.5~1.0 MPa

N2 Pressure Monitoring

Low pressure automatic alarm

N2 Consumption

(1.5h~2m3/h)/Pot

Air Pressure

4~6Kg/cm2

Air Pressure Monitoring

Low pressure automatic alarm

Air Source Flow

8~12L/min

Compressed Air Consumption

≤0.014m3/h

Power Supply

3P5W, 380VAC±10%, 50/60HZ

Power

3kw

14kw

12kw

30kw

32kw

36kw

Dimension (mm)

950*1060*1670

1350*1500*1650

1260*1360*1850

2850*1650*1850

4050*1650*1850

4050*1650*1850

Weight

300kg

650kg

700kg

1500kg

1900kg

2000kg
