Introduce of X-RAY 8300

Introduce：

The GDMR-8300 machine is designed to provide high resolution x-ray imaging primarily for the electronics industry. This versatile system is effective for many applications within the PCB manufacturing process. This includes BGA, CSP, QFN, Flip Chip, COB and the wide range of SMT components. The GDMR-8300 is a powerful support tool for process development, process monitoring and refinement of the rework operation. Supported by a powerful and easy to use software interface, GDMR-8300 is capable of addressing small and large volume factory requirements.

Features：

1.110kV 5µm closed X-ray tube, High Definition FPD with 2 mega pixels CCD camera

Accuracy: 99.99%(0201);

Compatibleminimumdevice type:01005 (unit: inch);

Thehighestpointing speed: about 6-10 seconds/4 plate

Calculatedbased on the minimum size of 01005 (unit: inch) 20,000 points;

7″ tray four trays at thesame timefeeding speed: about 8 seconds;

Timeincludingloading and unloading: about 11 seconds;

Supportmultiple sizesof material inventory (7″~15″);
